EU RoHSCompliant ECCN (US)EAR99Part StatusActiveHTS8542.39.00.01Driver TypeLow SideDriver ConfigurationNon-InvertingNumber of Drivers2Number of Outputs2Maximum Rise Time (ns)20Maximum Fall Time (ns)17Maximum Propagation Delay Time (ns)29Absolute Propagation Delay Time (ns)29Input Logic CompatibilityTTLMinimum Operating Supply Voltage (V)4.5Maximum Operating Supply Voltage (V)18Typical Input Low Threshold Voltage (V)1.2Typical Input High Threshold Voltage (V)1.6Maximum Supply Current (mA)0.95Peak Output Current (A)5(Typ)Minimum Operating Temperature (°C)-40Maximum Operating Temperature (°C)125Special FeaturesUnder Voltage LockoutPackagingTape and ReelLatch-Up ProofNoSupplier PackageSOICStandard Package NameSOPPin Count8MountingSurface MountPackage Height1.5(Max)Package Length4.9Package Width3.9PCB changed8Lead ShapeGull-wing
询价
