Absolute Maximum Ratings at Ta=25°C
Parameter Symbol Rating Unit
Input
Forward Current IF 50 mA
Reverse Voltage VR 6 V
Power Dissipation P 70 mW
Peak Forward Current
(100μs pulse, 100Hz frequency)
IFP 1 A
Thermal Resistance Junction-Ambient RthJ-A 325 oC/W
Thermal Resistance Junction-Case RthJ-C 200 oC/W
Output
Collector - Emitter Voltage VCEO 35 V
Emitter - Collector Voltage VECO 6 V
Collector Current IC 50 mA
Collector Power Dissipation PC 150 mW
Total Power Dissipation Ptot 200 mW
1. Isolation Voltage Viso 5000 Vrms
Operating Temperature (LTV-827/847) Topr -30 ~ +100
oC
Operating Temperature (LTV-817) Topr -50 ~ +110 oC
Storage Temperature Tstg -55 ~ +125 oC
Soldering Temperature Tsol 260 oC
